| LD1 AKC: Wide body aircraft. Half width lower deck container. |
 |
| Compatible aircraft: |
Boeing 747-400 Boeing 767 Boeing 747-400F Boeing 747-200F |
| Volume: |
170 cu.ft. (4.8cu.m.) |
| Tare Weight: |
85kg/187lbs |
| Max Gross Weight: |
1588kg/3493lbs |
| External Dimensions: |
92" x 30" x 64" x 61.5" x 60.4" |
|
|
| AKH: Wide body aircraft. Full width lower deck container. |
 |
| Compatible aircraft: |
Boeing 747-400 Boeing 767 Boeing 747-400F Boeing 747-200F |
| Volume: |
170 cu.ft. (4.8cu.m.) |
| Tare Weight: |
85kg/187lbs |
| Max Gross Weight: |
1588kg/3493lbs |
| External Dimensions: |
92" x 30" x 64" x 61.5" x 60.4" |
|
|
| LD3 AKE: Wide body aircraft. Half width lower deck container. |
 |
| Compatible aircraft: |
Boeing 747 400 Boeing 767 Boeing 777 Boeing 747-400F Boeing 747-200F MD11F |
| Volume: |
150 cu.ft. (4.2cu.m.) |
| Tare Weight: |
72kg/158lbs |
| Max Gross Weight: |
1588kg/3493lbs |
| External Dimensions: |
79" x 43" x 64" x 61.5" x 60.4" |
|
|
| LD26 AAF: Wide body aircraft. ALP: Full width lower deck container |
 |
| Compatible aircraft: |
Boeing 747-400 Boeing 777 Boeing 747-400F Boeing 747-200F MD11F |
| Volume: |
450 cu.ft. (12cu.m.) |
| Tare Weight: |
286kg/6033lbs |
| Max Gross Weight: |
747: 6033kg/13300lbs777: 4626kg/10501lbs |
| External Dimensions: |
160" x 66" x 125" x 88" |
|
|
| LD6 ALF: Wide body aircraft. Full width lower deck container. |
 |
| Compatible aircraft: |
Boeing 747-400 Boeing 777 Boeing 747-400F Boeing 747-200F |
| Volume: |
310 cu.ft. (8.8cu.m.) |
| Tare Weight: |
172kg/378lbs |
| Max Gross Weight: |
747: 3175kg/6985lbs |
| External Dimensions: |
41" x 160" x 46" x 125" x 64" |
|
|
| LD2 APE: Wide body aircraft. Half width lower deck container. |
 |
| Compatible aircraft: |
Boeing 767 |
| Volume: |
120 cu.ft. (3.4cu.m.) |
| Tare Weight: |
70kg/154lbs |
| Max Gross Weight: |
1225kg/2700lbs |
| External Dimensions: |
45" x 61.5" x 64" x 47" x 60.4" |
|
|
| LD9 AAP: Wide body aircraft. Full width lower deck container. |
 |
| Compatible aircraft: |
Boeing 747-400 Boeing 767 Boeing 777 Boeing 747-400F Boeing 747-200F MD11F |
| Volume: |
350 cu.ft. (10.0cu.m.) |
| Tare Weight: |
200kg/440lbs |
| Max Gross Weight: |
747: 6033kg/13300lbs777: 4626kg/10501lbs |
| External Dimensions: |
88" x 62" x 125" |
|
|
| LD11 ALP: Wide body aircraft. ALP: Full width lower deck container. |
 |
| Compatible aircraft: |
Boeing 747-400 Boeing 777 Boeing 747-400F Boeing 747-200F |
| Volume: |
240 cu.ft. (6.8cu.m.) |
| Tare Weight: |
185kg/407lbs |
| Max Gross Weight: |
747: 3176kg/6987lbs |
| External Dimensions: |
60.4" x 64" x 125" |
|
|
| LD29 AAU: Wide body aircraft. Full width lower deck container. |
 |
| Compatible aircraft: |
Boeing 747-400 Boeing 747-400F Boeing 747-200F |
| Volume: |
485 cu.ft. (13.9cu.m.) |
| Tare Weight: |
265kg/593lbs |
| Max Gross Weight: |
4626kg/10501lbs, Except one position (6033 kgs) |
| External Dimensions: |
186" x 29" x 62" x 125" x 88" |
|
|
